Mipi(CSI) Camera Module
We have professional capabilities from custom design to manufacturing of Mipi(CSI) camera modules, providing OEM and ODM services.
Mipi(CSI)camera modules can be fully customized to meet the needs of your project.
DGZX IMX258 13MP 4K 1080P Ultra HD AF HDR Wide Dynamic MIPI Camera Module
DGZX OS08A10 ULTRA HD 8MP 4K 2K Starlight Night Vision HDR Wide Dynamic Backlight Mipi Camera Module
DGZX BF20A1 MIPI VGA 0.3MP 480P 1/10″ CMOS Ultra-small structure facial recognition scanning camera module
DGZX GC02M1 2MP MIPI HD camera module supports ISP YUV output
DGZX GC1064 1MP 720P 60fps mipi camera module
DGZX GC5035 HD 5MP 2K 1080P MIPI distortion free camera module
DGZX HD 1MP 720P MIPI GC1054 wide angle distortion-free FPC camera module
DGZX IMX206 4K 16MP high resolution COMS MIPI camera module for outdoor low light industrial applications
DGZX IMX219 MIPI 8MP 180fps Autofocus Tablet Phone Camera Module
DGZX IMX307 2MP dual 1080P MIPI binocular HD starlight stereo vision camera module
Mipi(CSI) Camera module customized OEM/ODM manufacturers
Dogoozx is a Mipi(CSI) camera OEM manufacturer and supplier from China. We have provided Mipi(CSI) camera module customization and product manufacturing to many companies around the world, including Europe, the United States, the Middle East, South Korea, etc. We have been providing customers with high-quality, low-price, high-performance, competitive camera module products and solutions.
We have professional capabilities from custom design to manufacturing, providing OEM and ODM services. Mipi(CSI) camera modules can be fully customized to meet the needs of your project.
Benefits of choosing our OEM and customization services:
Professional OEM and ODM services
Industry-leading warranty services
Provide a set of customized solutions to meet your project needs
24-hour after-sales service to answer all kinds of questions for you.
What is a Mipi(CSI) camera module?
Mipi (CSI) camera module is a camera module based on MIPI (Mobile Industry Processor Interface) standard, where CSI stands for Camera Serial Interface. This camera module is widely used in embedded systems, mobile devices, security monitoring, machine vision and other fields, and is favored for its high-speed transmission, low power consumption, easy integration and high-quality images.
What are the components of Mipi(CSI) camera module?
Mipi (CSI) camera module mainly consists of the following key components:
1. Image Sensor
Function: The image sensor is the core component of the camera module and is responsible for converting optical images into electrical signals. It is usually made from CMOS (Complementary Metal Oxide Semiconductor) or CCD (Charge Coupled Device) technology.
Features: CMOS sensors are widely used in mobile devices due to their low power consumption, high integration and good image quality.
2. MIPI CSI interface
Function: The MIPI CSI interface is a communication bridge between the camera module and the processor or chip, responsible for transmitting image data at high speed and low latency.
Features: Supports differential signal transmission, providing high-speed data transmission rates while maintaining low power consumption.
3. Image processing unit (ISP)
Function: ISP (Image Signal Processor) is responsible for processing the original image data output by the image sensor, including denoising, color correction, automatic exposure, automatic white balance, etc.
Features: ISP can significantly improve image quality, making images clearer and colors more accurate.
4. Lens
Function: The lens is responsible for focusing light onto the image sensor to form a clear image.
Features: The quality of the lens directly affects the clarity and quality of the image. Some high-end camera modules may be equipped with functions such as autofocus and optical image stabilization.
5. Auxiliary circuits and components
Function: Including power management circuit, clock circuit, I2C/SPI and other control interface circuits, etc., used to support the normal operation of the camera module.
Features: Although these circuits and components are not directly involved in image acquisition and processing, they are an integral part of the camera module and have an important impact on the stability and performance of the module.
6. Housing and connectors
Function: The shell is used to protect the electronic components inside the camera module from the external environment; the connector is used to connect the camera module to the motherboard or other devices.
Features: The design of the housing should take factors such as heat dissipation, dustproof and waterproof into consideration; the selection of connectors should ensure the stability and reliability of signal transmission.
Mipi (CSI) camera module is a highly integrated system, consisting of multiple components such as image sensors, MIPI CSI interfaces, image processing units, lenses, and auxiliary circuits and components. These components work together to enable the collection, transmission and processing of high-quality images.
Types of MIPI Camera Modules
VGA Camera Modules
VGA camera modules are low-resolution camera modules. They usually have a resolution of 640 x 480 pixels, which is suitable for basic image and video capture.
CMOS Camera Modules
CMOS camera modules are widely used in modern devices such as smartphones. They offer better image quality and low power consumption. They are also more affordable than other camera modules.
CCD Camera Modules
CCD camera modules are often used in professional cameras and medical devices. They offer high image quality and better color reproduction, making them suitable for high-end applications.
Autofocus Camera Modules
Autofocus camera modules can adjust the focus by themselves and are commonly used in high-end smartphones and digital cameras to provide users with clear and sharp images.
Infrared (IR) Camera Modules
IR camera modules are specialized modules used to capture images in low-light conditions. They use infrared illumination to capture images and are used in security systems, surveillance cameras, and other specialized applications.
Application of MIPIcamera module
Industrial Automation and Machine Vision
In industrial settings, machine vision camera modules are used for activities such as quality control, inspection, and object recognition. These modules feature high-speed sensors, durable construction, and compliance with industrial protocols.
Smart Home Appliances
These modules enhance security systems, smart doorbells, and other home automation devices by providing visual input.
Smart Cities
In city surveillance and traffic management systems, MIPI camera modules facilitate real-time monitoring and data collection.
Medical Devices
Medical imaging devices, endoscopes, and diagnostic tools often employ MIPI camera modules for precise visualization.
Security Surveillance
Closed-circuit television (CCTV) cameras and surveillance systems rely on these modules to capture and transmit video footage.
Robotics
MIPI camera modules can be programmed to detect and track objects, enabling robots to navigate and operate autonomously.
Do-it-yourself (DIY) Projects
Raspberry Pi camera modules are popular for hobbyists and makers. These modules are used for projects that require photography, video recording, or computer vision. They allow hobbyists to explore creative applications.
MIPI camera module customization demand process
1. You can provide drawings or samples, or request files developed by our engineering staff.
2. Communication: We will communicate with you in detail to determine the products you need, and try to set up the most suitable products for you according to your needs.
3. Sample development: Determine the details and delivery time of the developed samples. Communicate at any time to ensure smooth progress.
4. Sample testing: Test and age according to your application, feedback the test results, no modification, and mass production.
Frequently asked questions about Mipi(CSI) camera modules
1.What is a 4k mipi camera module?
A: It is a high-performance camera module that supports image capture at 4K (3840x2160) resolution.
2.What is a 4k mipi camera module?
A: It is a high-performance camera module that supports image capture at 4K (3840x2160) resolution.
3.What is an ov5640 mipi camera module?
A: The OV5640 MIPI Camera Module uses the OV5640 image sensor produced by OmniVision as the core component, combined with high-quality optical lenses and carefully designed PCBAs to achieve high imaging quality.
4.What is the difference between DVP and MIPI?
A: A camera module is an image sensor that integrates lenses, control electronics, and interfaces such as CSI, Ethernet or ordinary raw low-voltage differential signals.
5.How does a MIPI camera work?
A: An image sensor or CSI-2 device captures an image and transmits it to the CSI-2 host where the SoC resides. Before the image is transmitted, it is placed in memory as individual frames. Each frame is then transmitted over the CSI-2 interface via a virtual channel.
6.What is the ESP32 CAM module?
A: The ESP32-CAM is a low-cost development board based on ESP32 with an onboard camera in a compact size. It is an ideal solution for IoT applications, prototyping, and DIY projects. The board integrates WiFi, classic Bluetooth, and low-power BLE, and is equipped with 2 high-performance 32-bit LX6 CPUs.
7.What is the Raspberry Pi Camera Module?
A: The Raspberry Pi Camera Board is an add-on module designed for Raspberry Pi hardware. It connects to the Raspberry Pi hardware via a custom CSI interface. In still shooting mode, the sensor has a native resolution of 5 megapixels. In video mode, it supports shooting up to 1080p resolution at 30 frames per second.
8.What is FPC in the camera?
A: FPC camera module is a small-sized camera module mounted on a flexible circuit board. It is small in size and easy to design and mechanically assemble. Only the sensor and camera lens are installed, and then connected to the processor through a flexible printed circuit board (FPC).
